Key Capabilities
IP68 Rated
Fully dust-tight and waterproof — built to survive the harshest warehouse environments.
4K Color Global Shutter Sensor
Captures distortion-free frames even on fast-moving forklifts. No motion blur, ever.
Low-Level Bluetooth Sync
Communicates with XMarkers via low-energy Bluetooth for seamless marker detection and coordination.
Indoor Localization
Precision indoor positioning using visual-inertial odometry and XMarker triangulation — no GPS needed.
NanoEye on the warehouse floor
Camera. Localiser. Computer.
Traditional warehouse perception requires separate cameras, positioning infrastructure, and server rooms. NanoEye puts all three in a single compact unit.
Vision System
Dual 4K wide-angle cameras with depth sensing capture rich visual data across the entire field of view. Automatic low-light adjustment for any warehouse environment.
- 4K stereo RGB
- 120-degree field of view
- 30fps continuous capture
Indoor Localisation
Built-in XMarker detection and visual odometry pinpoint the device's position within the warehouse without any external infrastructure.
- Sub-metre accuracy
- XMarker detection
- Visual-inertial odometry
Edge Compute
On-device AI processes frames in real time. Pallet detection, movement classification, and slot identification happen at the edge — no cloud latency.
- 12 TOPS neural engine
- On-device inference
- <100ms detection latency
Built for the warehouse floor
Dimensions
142 x 86 x 38mm
Weight
320g
Ingress Rating
IP67
Operating Temp
-20 to 55 C
Battery Life
12hr shift
Hot-Swap
Zero downtime
Connectivity
Wi-Fi 6 / 5G
Processing
12 TOPS
Installs in under 10 minutes
Magnetic mount or bracket. No wiring. No forklift modifications. Power on and the device auto-calibrates.
Mount
Attach to any forklift mast or overhead guard using the magnetic mount or universal bracket.
Power on
Insert the hot-swap battery pack. NanoEye boots and connects to your Wi-Fi network automatically.
Calibrate
The device runs a 60-second auto-calibration routine. No manual setup required.
